Description
Technical Parameters
| MODEL | ES-15P | ||
| parameter |
power form | electric | |
| operation form |
walkie |
||
| rated load capacity | kg | 1500 | |
|
rated load center to center distance |
mm | 500 | |
| front overhang | mm | 667 | |
| wheelbase | mm | 1088 | |
| net weight | dead weight | kg | 588 |
| tires and track width | tire form |
rubber solid tire |
|
| Front tire specifications | 380x100 | ||
| Rear tire specifications | 400x105 | ||
| Number of tires (x=driving wheels) | 1x2 | ||
| Front wheelbase | mm | / | |
| Rear wheelbase | mm | 1230 | |
| size parameter | Standard gantry lifting height | mm | 2210 |
| Total length | mm | 1790 | |
| The length of the vehicle body to the vertical plane of the fork | mm | 720 | |
| Total width | mm | 1070/1250 | |
| Fork size (thickness * width * length) | mm | 35/100/1070 | |
| Distance between forks | mm | 210-850 | |
| At the gantry, minimum ground clearance | mm | 150 | |
| Right angle stacking channel (AsT800x 12001200 along fork) | mm | 2129 | |
| minimum turning radius | mm | 1428 | |
| performance | Maximum driving speed (full loadino load) | km/h | 5.5/5.5 |
| Maximum lifting speed (full loadino load) | mm's | 46/61 | |
| Descent speed (full load/no load) | mm's | 56/58 | |
| Maximum Climbing Slope (Full Load/Empty Load) | % | 6/8 | |
| Parking brake (mechanical, electronic, hydraulic) | Electric | ||
| Motor | Power of walking motor, S260min working system | kw | 1.1 |
| Power of lifting motor, S315min working system | kw | 0.8 | |
| Standard battery voltage/capacity | v/ah | 48/32 | |
| Standard battery weight | kg | 41.2 | |
| Controller | Walking control form | DC | |
| Controller | Domestic |
◆Load capacity:1.5T-2.5T
◆Driving on uneven and rough surfaces
◆straddle legs electric stacker
◆Diverse height ranges to meet users' needs
◆Wide wheel base for added stability
◆Standard battery:lead-acid battery 48V32Ah
