| model | FTTS15 | |
| Power Type | electric | |
| Operation type | Ride-on | |
| Rated load | KG | 1500 |
| Load center distance | mm | 600 |
| Weight (including battery) | KG | 7020 |
| Tire type, driving wheel/load wheel (steering wheel) | Polyurethane | |
| Mast height after lowering | mm | 3460 |
| Standard maximum lifting height | mm | 6500 |
| Mast height when lifted to the highest position | mm | 7695 |
| Height of roof guard (cabin) | 2346 | |
| Vehicle length | 3048 | |
| Overall width | 1270/1500 | |
| Fork size | 50/120/1200 | |
| External width of backrest | 860 | |
| External width of fork | 340-800 | |
| Turning radius | 2185 | |
| Travel speed, fully loaded/unloaded | km/ h | 10/10.5 |
| Lifting speed, full load/no load | m/s | 0.4/0.47 |
| Lowering speed, full load/no load | m/s | 0.55/0.45 |
| Battery voltage/nominal capacity | V/Ah | 48/560 |
Why book with us?
Customized demand, strong adaptability
1. It can adapt to different types of shelves and storage needs, whether it is high-level shelves or low-level shelves, it can easily cope with it
2. It can be adjusted and optimized according to the specific layout of the warehouse to meet the actual needs of the enterprise.
Optimize processes and improve efficiency
There is no need to turn in the shelf aisle. The fork can rotate 180° and move left and right to quickly and accurately reach various positions on the shelf, realizing free storage and stacking of goods on both sides.
Reasonable space layout, more comfortable driving
The spacious cab and reasonable control layout provide the driver with a comfortable and efficient working environment. It maintains stability during high-speed movement and heavy-load operation, reduces cargo damage and operating errors, and ensures safety and efficiency of operations.
