Products Description
| Serial number | Name | International unit (code) | |
| 1.1 | Power type | Electric | |
| 1.2 | Operation type | Walk-behind | |
| 1.3 | Rated load | KG | 800 (fork load 2000) |
| 1.4 | Load center distance | MM | 600 |
| 1.5 | Weight (including battery) | KG | 660 |
| 1.6 | The lowest height of the mast after lowering | MM | 1860 |
| 1.7 | Mast travel | MM | 1480 |
| 1.8 | Mast lifting height (fork surface to ground) | MM | 1685 |
| 1.9 | Height of fork after lowering | MM | 95 |
| 1.10 | Vehicle length | MM | 1776 |
| 1.11 | Overall width | MM | 738/710 |
| 1.12 | Fork outer width | MM | 560 |
| 1.13 | Right angle stacking channel width (pallet is 1000 length × 1200 width) | MM | 2274 |
| 1.14 | Right angle stacking channel width (pallet is 800 width × 1200 length) | MM | 2198 |
| 1.15 | Turning radius | MM | 1442 |
| 1.16 | Travel speed, full load/no load | km/h | 5/5.5 |
| 1.17 | Lifting speed, full load/no load | m/s | 0.14/0.2 |
| 1.18 | Battery voltage/nominal capacity | V/Ah | 4*6v/224Ah |
that's our services
Lorem ipsum dolor, sit amet consectetur adipisicing elit.
High performance, high reliability
High-strength vertical gearbox, ultra-long working life;
Low-noise and low-fault hydraulic station, cylinders and pipelines that have undergone multiple layers of testing, ensuring high reliability of the hydraulic system;
Reliable quality American AMP waterproof connectors and electrical components, all wires and cables are reliably protected and fixed, greatly reducing electrical failures.
More secure
The explosion-proof design of the hydraulic system ensures that the mast will not drop rapidly even if the oil pipe bursts, thus improving
safety;
Emergency reverse driving function to prevent the operator from getting hurt;
Emergency power off switch can easily cut off all power supply in case of out-of-control operation to avoid emergency accidents;
Multiple lifting limits make stacking safer.
The anti-skid braking function prevents the car from sliding down when it is out of control or driving on a slope.
Easy to operate
The handle head design fully considers ergonomics, and each function button is easy to operate;
Double pallet lifting improves work efficiency;
The longer control handle greatly reduces the force required to operate the vehicle, making it easier to operate.
Easy maintenance
AC motor, maintenance-free;
Timer and power meter are configured to remind the operator to charge in time and protect the battery;
Easy to disassemble and assemble the machine body. By removing the rear cover, the main key components can be inspected, repaired and replaced;
The use of upright motors makes the inspection and maintenance of motors, brakes, etc. direct and convenient, and the maintenance performance is much better than that of horizontal motors:
The controller self-diagnosis system displays fault codes through the handheld unit, making it easier to solve faults;
Automatic low voltage protection to extend battery life
